WWE 230
General Information
230ft x 70ft x 14ft flat top cargo barge, 2 spuds, and 20t/m2 deck space.
Technical specifications
| General | |
| Year/Place Built | 2025/ Batam |
| Flag | Singapore |
| Class | RINA |
| Main Dimensions | |
| Length | 70,10 m/ 230ft |
| Breadth | 21.33 m / 70ft |
| Depth empty | 0.8m/ 2.6ft |
| Summer draft | 3.4m / 11.1ft |
| Clear deck area | 910 m2 |
| Deck Strength | 20 t/m2 |
| Navigation lights | solar powered |
| DWT | 3500 ton |
| Outfitting | |
| Mooring bollards | 8 x double bits / 20t SWL |
| Smit Brackets | 4 x 100T SWL |
| Spud holes | 4 x 1.25m diameter |
| Fair leads | Universal Box roller type |
| Navigation lights | Solar powered |
| SPUD LIFTING SYSTEM |
|
| Spud Length | 2 x 24,2 m x 1.2 mtr dia |
| Spud wire dia | 42 mm x 16m |
| HPU PARAMETERS |
|
| Power | 15 KW |
| Speed | 1480 RPM |
| Max Pressures | 250 Bar |
| Hyd Oil tank | 255 liter |
